MODELING SEASONAL VARIATION OF CO2 FLUX IN A SUBTROPICAL CONIFEROUS FOREST USING THE EALCO MODEL

doi:10.17521/cjpe.2007.0140

Abstract

Abstract:

Aims Seasonal drought frequently occurs in the mid-subtropical region of China and commonly combines with high temperature. Our objectives were to test the sensitivity of carbon exchange to this seasonal drought and discuss the influence of seasonal drought on carbon assimilation.

Methods We used flux measurements obtained from eddy covariance technology since October 2002 over a human-planted forest ecosystem at Qianyanzhou (QYZ) (26°44' N, 115°03' E, 110.8 m als.). The EALCO (ecological assimilation of land and climate observations) model is parameterized to simulate the ecosystem carbon exchange process in the human-planted evergreen forest. Simulation results were validated using half-hourly carbon fluxes and daily and annualGPP (gross primary production), NEP (net ecosystem production) and TER (total ecosystem respiration) estimated from eddy covariance measurements.

Important findings In general, the model can effectively simulate the two years' carbon fluxes among soil-plant-atmosphere on hourly, daily and annual scales. Both simulations and observations showed strong impact of drought on GPP in 2003. Compared with 2004, the annual GPP in 2003 was 12.9% lower according to observations (1 610 vs. 1 865 g C·m^-2) and 11.2% lower according to model results (1 637 vs. 1 844 g C·m^-2). The diurnal variations of NEP from both observations and simulations during the period of soil water deficit showed asymmetric format, i.e., the peak value of carbon exchange accrued at a certain time in the morning and then decreased with time. Modeling results indicated that water stress has more influence on photosynthesis than TER, which led to the decrease of NEP. Further analysis suggested that deep soil water content controls canopy photosynthesis in sunny days before noon during soil water stress. Afternoon, both high temperature and deep soil water content eliminate the GPP, and their elimination percents are equal. On cloudy days, radiation and deep soil water content primarily determine the photosynthesis, and temperature becomes a generally minor controlling factor.

Key words: coniferous plantation, carbon flux, EALCO model, ecosystem processes, seasonal drought

MI Na, YU Gui-Rui, WANG Pan-Xing, WEN Xue-Fa, SUN Xiao-Min, ZHANG Lei-Ming, SONG Xia, WANG Shu-Sen. MODELING SEASONAL VARIATION OF CO₂ FLUX IN A SUBTROPICAL CONIFEROUS FOREST USING THE EALCO MODEL[J]. Chin J Plant Ecol, 2007, 31(6): 1119-1131.

Add to citation manager EndNote|Ris|BibTeX

URL: https://www.plant-ecology.com/EN/10.17521/cjpe.2007.0140

https://www.plant-ecology.com/EN/Y2007/V31/I6/1119

Figures/Tables 12

References 33

[1]	Abdella K, McFarlane NA (1996). Parameterization of the surface-layer exchange coefficients for atmospheric models. Boundary-Layer Meteorology, 80,223-248.
[2]	Amthor JS (1989). Respiration and Crop Productivity. Springer Verlag , New York.
[3]	Amthor JS, Chen JM, Clein JS, Frolking SE, Goulden ML, Grant RF, Kimball JS, King AW, Mcguire AD, Nikolov NT, Potter CS, Wang SS, Wofsy SC (2001). Boreal forest CO ₂ exchange and evapotranspiration predicted by nine ecosystem process model: intermodel comparisons and relationships to field experiments. Journal of Geography Research—Atmosphere, 106,33623-33648.
[4]	Ball JT, Woodrow IE, Berry JA (1987). A model predicting stomatal conductance and its contribution to the control of photosynthesis under different environmental conditions. In: Biggens Jed. Progress in Photosynthesis Research. Vol. 4. Martinus-Nijhoff, Dordrecht,221-224.
[5]	Cao M, Woodward FI (1998). Dynamic responses of terrestrial ecosystem carbon cycling to global climate change. Nature, 393,249-252.
[6]	Chen YR (陈永瑞) (2000). Nutrient element dynamic analysis of withered leaves from artificial forest of masson pine on the experimental plot in Qiangyanzhou. Jiangxi Science (江西科学), 18,19-24. (in Chinese with English abstract)
[7]	Cox P, Friedlingstein P, Rayner P (2002). Modeling climate carbon cycle feedbacks: a cross disciplinary collaboration priority. IGBP Global Change Newsletter, 49,12-14.
[8]	Falge E, Baldocchi D, Olson R (2001). Gap filling strategies for defensible annual suns of net ecosystem exchange. Agriculture and Forest Meteorology, 107,43-69.
[9]	Farquhar GD, Von Caemmerer S, Berry JA (1980). Abiochemical model of photosynthetic CO ₂ assimilation in leaves of C₃ species. Planta, 149,78-90. DOI URL PMID
[10]	Grant RF (2001), A review of the Canadian ecosystem model ecosys. In: Shaffer MJ, Ma L, Hansen Seds. Modeling Carbon and Nitrogen Dynamics for Soil Management. CRC Press, Boca Raton,173-263.
[11]	Grant RF, Arain A, Arora V, Barr A, Black TA, Chen J, Wang S, Yuan F, Zhang Y (2005). Intercomparison of technique to model high temperature effects on CO ₂ and energy exchange in temperate and boreal coniferous forests. Ecological Modelling, 188,217-252.
[12]	Hanson PJ, Weltzin JF (2000). Drought disturbances from climate change: response of United States forests. Science of the Total Environment, 262,205-220.
[13]	Huang DY (黄道友), Wang KL (王克林), Huang M (黄敏), Chen HS (陈洪松), Wu JS (吴金水), Zhang GP (张广平), Peng TB (彭廷柏) (2004). Seasonal drought problems in the red soil hilly region of the middle subtropical zone of China. Acta Ecologica Sinica (生态学报), 24,2516-2523. (in Chinese with English abstract)
[14]	Ito A, Olikawa T (2002). A simulation model of the carbon cycle in land ecosystems (Sim-CYCLE): a description based on dry matter production theory and plot-scale validation. Ecological Modelling, 151,143-176.
[15]	Kimmins JP (1997). Forest Ecology: a Foundation for Sustainable Management 2nd edn. Prentice Hall, New Jersey.
[16]	Larcher W (1995). Physiological Plant Ecology 3rd edn. Springer, Austria.
[17]	Li XR (李轩然), Liu QJ (刘琪王景), Cai Z (蔡哲), Ma ZQ (马泽清) (2007). Specific leaf area and leaf area index of conifer plantation in Qianyanzhou station of subtropical China. Journal of Plant Ecology (Chinese Version)(植物生态学报), 31,93-101. (in Chinese with English abstract)
[18]	Liu RF, Song X, Yu GR, Sun XM, Wen XF, Chen YR (2004). Seasonal variation of CO ₂ flux and its environmental factors in evergreen coniferous plantation. Science in China Series D, 48(Suppl. Ⅰ),123-133.
[19]	Liu RF, Yu GR, Wen XF, Wang YH, Song X, Li J, Sun XM, Yang FT, Chen YR, Liu QJ (2006). Seasonal dynamics of CO ₂ fluxes from sub-tropical plantation coniferous ecosystem. Science in China Series D, 49(Suppl.Ⅱ),99-109.
[20]	Ma L, Shaffer MJ (2001). A review of carbon and nitrogen processes in nine US soil nitrogen dynamic models. In: Shaffer MJ, Ma L, Hansen Seds. Modeling Carbon and Nitrogen Dynamics for Soil Management. CRC Press, Boca Raton,55-102.
[21]	McGechan MB, Wu L (2001). A review of carbon and nitrogen processes in European soil nitrogen dynamic models. In: Shaffer MJ, Ma L, Hansen Seds. Modeling Carbon and Nitrogen Dynamics for Soil Management. CRC Press, Boca Raton,103-172.
[22]	Peng C, Jiang H, Apps MJ, Zhang Y (2002). Effects of harvesting regimes on carbon and nitrogen dynamics of boreal forests in central Canada: a process model simulation. Ecological Modelling, 155,177-189.
[23]	Riedo M, Gyalistras D, Fuhrer J (2000). Net primary production and carbon stocks in differently managed grasslands: simulation of site-specific sensitivity to an increase in atmospheric CO ₂ and to climate change. Ecological Modeling, 134,207-227.
[24]	Sharpe PSH, DeMichelle DW (1977). Reaction kinetics of poikilothermic development. Journal of Theoretical Biology, 64,649-670. DOI URL PMID
[25]	Song X (宋霞), Liu RF (刘允芬), Xu XF (徐晓锋), Yu GR (于贵瑞), Wen XF (温学发) (2004). Comparison study on carbon dioxide, water and heat fluxes of the forest ecosystem in red earth hilly zone over winter and spring. Resources Science (资源科学), 26(3),96-104. (in Chinese with English abstract)
[26]	Verseghy DL, McFarlane NA, Lazare M (1993). CLASS—a Canadian land surface scheme for GCMs. Ⅱ. Vegetation model and coupled runs. International Journal of Climatology, 13,347-370.
[27]	Wang S, Davidson A (2007). Impact of climate variations on surface albedo of a temperate grassland. Agricultural and Forest Meteorology, 142,133-142.
[28]	Wang S, Grant R, Verseghy DL, Black TA (2001). Modeling plant carbon and nitrogen dynamics of a boreal aspen forest in CLASS—the Canadian Land Surface Scheme. Ecological Modeling, 142,135-155.
[29]	Wang S, Grant R, Verseghy DL, Black TA (2002a). Modeling carbon-coupled energy and water dynamics of a boreal aspen forest in a general circulation model land surface scheme. International Journal of Climatology, 22,1249-1265.
[30]	Wang S, Grant R, Verseghy DL, Black TA (2002b). Modeling carbon dynamics of boreal forest ecosystems using the Canadian Land Surface Scheme. Climate Change, 55,451-477.
[31]	Wang S, Trishchenko A, Khlopenkov K, Davidson A (2006). Comparison of IPCC AR4 climate model simulations of surface albedo with satellite products over northern latitudes. Journal of Geography Research—Atmosphere, 111,D21108, doi: 10.1029/2005JD006728.
[32]	Zhang LM, Yu GR, Sun XM, Wen XF, Ren CY, Song X, Liu YF, Guan DX, Yan JH, Zhang YP (2006). Seasonal variation of carbon exchange of typical forest ecosystems along the eastern forest transect in China. Science in China Series D, 49 (Suppl.Ⅱ),47-62.
[33]	Zhou ZT (周志田), Chen SK (成升魁), Liu RF (刘允芬), Li JY (李家永) (2002). CO ₂ emission of soil under different land-use types in subtropical red soil hilly areas in China: preliminary exploration. Resources Science (资源科学), 24(2),83-88. (in Chinese with English abstract)

符号 Symbol	描述 Description	取值 Value	单位 Unit	来源 Source
φ_c,min	式(3)	-200	m H₂O	Larcher, 1995; Kimmins, 1997
φ_c,max	式(3)	0	m H₂O	Larcher, 1995; Kimmins, 1997
m	式(6)	7		Ball et al., 1987
b	式(6)	0.008	mol·m^-2·s^-1	Ball et al., 1987
r_m,F	式(10), 叶 Leaf	4.8×10^-8	Kg C·kg C^-1·S^-1	Amthor, 1989
r_m,S	式(10), 茎 Stem	1.6×10^-8	Kg C·kg C^-1·S^-1	Amthor, 1989
r_m,S	式(10), 根 Root	2.4×10^-8	Kg C·kg C^-1·S^-1	Amthor, 1989
A	式(11)	8.8(16.9^*)
S	式(11)	710(710^*)	J·K^-1·mol^-1
H_a	式(11)	36 000(57 500^*)	J·mol^-1
H_dh	式(11)	220 000(226 000^*)	J·mol^-1
H_dl	式(11)	175 000(192 000^*)	J·mol^-1
r_g,X	式(12)	0.42		Amthor, 1989
V_cmax	最大羧化能力 Maximum catalytic activity of Rubisco	35	μmol·m^-2·s^-1	Farquhar et al., 1980
J_max	最大电子传递速 Potential rate of whole-chain electron transport	87	μmol·m^-2·s^-1	Farquhar et al., 1980
TreeDesi	树的密度Density of tree	0.199 1	trees·m^-2	宋霞等, 2004
SLA	比叶面积Specific leaf area	12	m²·kg^-1	李轩然等, 2007
ζ	决定凋落量的系数 Coefficient	0.000 2	(DOY210~250)	本研究 This study
		0.000 65	(DOY250~365)
Clay	粘土百分含量 Percent of clay	18	%	CERN数据 CERN tada
Sand	沙土百分含量 Percent of sand	20	%	CERN数据 CERN tada
SOM	有机物质含量 Content of soil organic matter	3	%	周志田等, 2002
SOILC	土壤碳含量 Content of soil carbon	8.76(6.80^**)	Kg C·m^-2	自运行后2003年1月1日的值 Data simulated from January 1, 2003
SOILN	土壤氮含量 Content of soil nitrogen	0.87	Kg N·m^-2	自运行后2003年1月1日的值 Data simulated from January 1, 2003

符号 Symbol	描述 Description	取值 Value	单位 Unit	来源 Source
φ_c,min	式(3)	-200	m H₂O	Larcher, 1995; Kimmins, 1997
φ_c,max	式(3)	0	m H₂O	Larcher, 1995; Kimmins, 1997
m	式(6)	7		Ball et al., 1987
b	式(6)	0.008	mol·m^-2·s^-1	Ball et al., 1987
r_m,F	式(10), 叶 Leaf	4.8×10^-8	Kg C·kg C^-1·S^-1	Amthor, 1989
r_m,S	式(10), 茎 Stem	1.6×10^-8	Kg C·kg C^-1·S^-1	Amthor, 1989
r_m,S	式(10), 根 Root	2.4×10^-8	Kg C·kg C^-1·S^-1	Amthor, 1989
A	式(11)	8.8(16.9^*)
S	式(11)	710(710^*)	J·K^-1·mol^-1
H_a	式(11)	36 000(57 500^*)	J·mol^-1
H_dh	式(11)	220 000(226 000^*)	J·mol^-1
H_dl	式(11)	175 000(192 000^*)	J·mol^-1
r_g,X	式(12)	0.42		Amthor, 1989
V_cmax	最大羧化能力 Maximum catalytic activity of Rubisco	35	μmol·m^-2·s^-1	Farquhar et al., 1980
J_max	最大电子传递速 Potential rate of whole-chain electron transport	87	μmol·m^-2·s^-1	Farquhar et al., 1980
TreeDesi	树的密度Density of tree	0.199 1	trees·m^-2	宋霞等, 2004
SLA	比叶面积Specific leaf area	12	m²·kg^-1	李轩然等, 2007
ζ	决定凋落量的系数 Coefficient	0.000 2	(DOY210~250)	本研究 This study
		0.000 65	(DOY250~365)
Clay	粘土百分含量 Percent of clay	18	%	CERN数据 CERN tada
Sand	沙土百分含量 Percent of sand	20	%	CERN数据 CERN tada
SOM	有机物质含量 Content of soil organic matter	3	%	周志田等, 2002
SOILC	土壤碳含量 Content of soil carbon	8.76(6.80^**)	Kg C·m^-2	自运行后2003年1月1日的值 Data simulated from January 1, 2003
SOILN	土壤氮含量 Content of soil nitrogen	0.87	Kg N·m^-2	自运行后2003年1月1日的值 Data simulated from January 1, 2003

变量 Item	年 Year	斜率 Slope	截距 Intercept	R²	标准差 Standard deviation	记录数 Observations
净CO₂交换量	2003	0.91	-0.34	0.68	3.66	12 849
Net CO₂ flux (NEP)	2004	0.91	-0.02	0.67	4.17	13 141
	2003~2004	0.91	-0.18	0.68	3.93	25 990

变量 Item	年 Year	斜率 Slope	截距 Intercept	R²	标准差 Standard deviation	记录数 Observations
净CO₂交换量	2003	0.91	-0.34	0.68	3.66	12 849
Net CO₂ flux (NEP)	2004	0.91	-0.02	0.67	4.17	13 141
	2003~2004	0.91	-0.18	0.68	3.93	25 990

变量 Variable	2003		2004
变量 Variable	模拟值 Simulation	估算值 Estimated¹⁾	模拟值 Simulation	估算值 Estimated¹⁾
GPP	1 637.5	1 610.4	1 844.1	1 865.8
NPP	546.8	-	728.9	-
NEP	404.4	387.2	582.1	423.8
R_above	-765.8	-	-768.3	-
R_soil	-467.3	-	-493.7	-536.5
TER	-1 233.1	-1 223.3	-1 262.0	-1 442.0
