Chin J Plant Ecol ›› 2014, Vol. 38 ›› Issue (1): 36-44.DOI: 10.3724/SP.J.1258.2014.00004
• Research Articles • Previous Articles Next Articles
GUO Jing-Heng1,2,3,4,5, ZENG Fan-Jiang1,2,3,4,*(), LI Chang-Jun1,2,3,4,5, ZHANG Bo1,2,3,4,5
Received:
2013-08-12
Accepted:
2013-11-10
Online:
2014-08-12
Published:
2014-01-15
Contact:
ZENG Fan-Jiang
GUO Jing-Heng, ZENG Fan-Jiang, LI Chang-Jun, ZHANG Bo. Root architecture and ecological adaptation strategies in three shelterbelt plant species in the southern Taklimakan Desert[J]. Chin J Plant Ecol, 2014, 38(1): 36-44.
Add to citation manager EndNote|Ris|BibTeX
URL: https://www.plant-ecology.com/EN/10.3724/SP.J.1258.2014.00004
Fig. 1 The natural environmental characteristics in the study area. A, Tamarix ramosissima. B, Haloxylon ammodendron. C, Populus alba var. pyramidalis.
Fig. 2 The schematic illustration of root branching system. The d is diameter before branching, d1, d2 and d3 are diameters after branching (after Oppelt et al. 2001).
物种 Species | A | b | Pe | v0 | qa | qb | TI |
---|---|---|---|---|---|---|---|
多枝柽柳 Tamarix ramosissima | 25.25 ± 1.55 b | 8.91 ± 0.22 b | 423.33 ± 29.36 c | 47.08 ± 2.39 c | 0.46 ± 0.02 b | 0.13 ± 0.02 b | 0.84 ± 0.01 b |
梭梭 Haloxylon ammodendron | 46.83 ± 2.87 a | 12.72 ± 0.32 a | 898.17 ± 63.57 b | 70.33 ± 3.8 b | 0.63 ± 0.01 a | 0.19 ± 0.01 a | 0.90 ± 0.01 a |
新疆杨 Populus albavar. pyramidalis | 10.83 ± 0.48 c | 8.85 ± 0.19 b | 1 088.33 ± 34.73 a | 123.33 ± 5.1 a | 0.03 ± 0.01 c | 0.02 ± 0.01 c | 0.49 ± 0.01 c |
Table 1 The parameters of root system topology structures of three shelterbelt plant species (mean ± SE)
物种 Species | A | b | Pe | v0 | qa | qb | TI |
---|---|---|---|---|---|---|---|
多枝柽柳 Tamarix ramosissima | 25.25 ± 1.55 b | 8.91 ± 0.22 b | 423.33 ± 29.36 c | 47.08 ± 2.39 c | 0.46 ± 0.02 b | 0.13 ± 0.02 b | 0.84 ± 0.01 b |
梭梭 Haloxylon ammodendron | 46.83 ± 2.87 a | 12.72 ± 0.32 a | 898.17 ± 63.57 b | 70.33 ± 3.8 b | 0.63 ± 0.01 a | 0.19 ± 0.01 a | 0.90 ± 0.01 a |
新疆杨 Populus albavar. pyramidalis | 10.83 ± 0.48 c | 8.85 ± 0.19 b | 1 088.33 ± 34.73 a | 123.33 ± 5.1 a | 0.03 ± 0.01 c | 0.02 ± 0.01 c | 0.49 ± 0.01 c |
物种 Species | Rb | R1/R2 | R2/R3 | R3/R4 | R4/R5 |
---|---|---|---|---|---|
多枝柽柳 Tamarix ramosissima | 3.23 ± 0.08 c | 5.04 ± 0.57 b | 3.19 ± 0.19 b | 3.00 ± 0.13 b | 2.78 ± 0.26 a |
梭梭 Haloxylon ammodendron | 3.72 ± 0.09 b | 8.83 ± 1.48 a | 3.15 ± 0.14 b | 3.46 ± 0.29 b | 2.95 ± 0.43 a |
新疆杨 Populus albavar. pyramidalis | 8.20 ± 0.13 a | 11.10 ± 0.74 a | 11.20 ± 0.41 a | 11.82 ± 0.26 a | 2.23 ± 0.08 a |
Table 2 The total root bifurcation ratio (Rb) and stepwise root bifurcation ratio (Ri/Ri+1) of three shelterbelt plant species (mean ± SE)
物种 Species | Rb | R1/R2 | R2/R3 | R3/R4 | R4/R5 |
---|---|---|---|---|---|
多枝柽柳 Tamarix ramosissima | 3.23 ± 0.08 c | 5.04 ± 0.57 b | 3.19 ± 0.19 b | 3.00 ± 0.13 b | 2.78 ± 0.26 a |
梭梭 Haloxylon ammodendron | 3.72 ± 0.09 b | 8.83 ± 1.48 a | 3.15 ± 0.14 b | 3.46 ± 0.29 b | 2.95 ± 0.43 a |
新疆杨 Populus albavar. pyramidalis | 8.20 ± 0.13 a | 11.10 ± 0.74 a | 11.20 ± 0.41 a | 11.82 ± 0.26 a | 2.23 ± 0.08 a |
Fig. 4 Ratio of root cross-sectional areas in three shelterbelt plant species. Relationships between ratio of root cross-sectional areas and root diameter were fitted with a linear model. A, Tamarix ramosissima. B, Haloxylon ammodendron. C, Populus alba var. pyramidalis.
[1] | Berntson GM (1995). The characterization of topology: a comparison of four topological indices for rooted binary trees. Journal of Theoretical Biology, 177,271-281. |
[2] | Biondini ME, Grygiel CE (1994). Landscape distribution of organisms and the scaling of soil resources. The American Naturalist, 143,1026-1054. |
[3] | Bouma TJ, Nielsen KL, Vanhal J, Koutstaal B (2001). Root system topology and diameter distribution of species from habitats differing in inundation frequency. Functional Ecology, 15,360-369. |
[4] | Brandle JR, Hodges L, Zhou XH (2004). Windbreaks in North American agricultural systems. New Vistas in Agroforestry, 1,65-78. |
[5] | Brandle JR, Johnson BB, Akeson T (1992). Field windbreaks: Are they economical? Journal of Production Agriculture, 5,393-398. |
[6] | Dannowski M, Block A (2005). Fractal geometry and root system structures of heterogeneous plant communities. Plant and Soil, 272,61-76. |
[7] | Eduardo S, Harry OL, Pekka N (2004). A fractal root model applied for estimating the root biomass and architecture in two tropical legume tree species. Annals of Forest Science, 61,337-345. |
[8] | Fan ZP, Zeng DH, Zhu JJ, Jiang FQ, Yu XX (2002). Advance in characteristics of ecological effects of farmland shelter- belts. Journal of Soil and Water Conservation, 16(4),130-140. (in Chinese with English abstract) |
[ 范志平, 曾德慧, 朱教君, 姜凤岐, 余新晓 (2002). 农田防护林生态作用特征研究. 水土保持学报, 16(4),130-140.] | |
[9] | Fitter AH (1986). The topology and geometry of plant root systems: influence of watering rate on root system topol- ogy in Trifolium pratense. Annals of Botany, 58,91-101. |
[10] | Fitter AH (1987). An architectural approach to the comparative ecology of plant root systems. New Phytologist, 106,61-77. |
[11] | Fitter AH, Stickland TR, Harvey ML, Wilson GW (1991). Architectural analysis of plant root systems 1. Architectural correlates of exploitation efficiency. New Phytologist, 118,375-382. |
[12] | Fitter AH, Sticklabd TR (1991). Architectural analysis of plant root systems 2. Influence of nutrient supply on architecture in contrasting plant species. New Phytologist, 118,383-389. |
[13] | Glimskär A (2000). Estimates of root system topology of five plant species grown at steady-state nutrition. Plant and Soil, 227,249-256. |
[14] | Guswa J (2010). Effect of plant uptake strategy on the water-optimal root depth. Water Resources Research, 46, doi:10.1029/2010WR0091222. |
[15] | Hodge A (2003). The plastic plant, root responses to heteroge- neous supplies of nutrients. New Phytologist, 162,9-24. |
[16] | Hodge A, Berta G, Doussan C, Merchan F, Crespi M (2009). Plant root growth, architecture and function. Plant and Soil, 321,153-187. |
[17] | Martínez-Sánchez JJ, Ferrandis P, Trabaud L, Galindo R, Franco JA, Herranz JM (2003). Comparative root system structure of post-fire Pinus halepensis Mill .and Cistus monspeliensis L .saplings. Plant Ecology, 168,309-320. |
[18] | Oppelt AL, Kurth W, Dzierzonb H, Jentschke G, Godbold D (2000). Structure and fractal dimensions of root systems of four co-occurring fruit tree species from Botswana. Annals of Forest Science, 57,463-475. |
[19] | Oppelt AL, Kurth W, Godbold DL (2001). Topology, scaling relations and Leonardo’s rule in root systems from African tree species. Tree Physiology, 21,117-128. |
[20] | Oppelt AL, Kurth W, Jentschke G, Godbold DL (2005). Contrasting rooting patterns of some arid-zone fruit tree species from Botswana-II. Coarse root distribution. Agroforestry Systems, 64,1-11. |
[21] | Schenk HJ, Jackson RB (2002a). Rooting depths, lateral root spreads and below-ground/above-ground allometries of plants in water-limited ecosystems. Journal of Ecology, 90,480-494. |
[22] | Schenk HJ, Jackson RB (2002b). The global biogeography of roots. Ecological Monographs, 73,311-328. |
[23] | Shan LS, Li Y, Dong QL, Geng DM (2012). Ecological adapta- tion of Reaumuria soongorica root system architecture to arid environment. Journal of Desert Research, 32,1283-1290. (in Chinese with English abstract) |
[ 单立山, 李毅, 董秋莲, 耿东梅 (2012). 红砂根系构型对干旱的生态适应. 中国沙漠, 32,1283-1290.] | |
[24] |
Shan LS, Li Y, Ren W, Su SP, Dong QL, Geng DM (2013). Root architecture of two desert plants in central Hexi Corridor of Northwest China. Chinese Journal of Applied Ecology, 24,25-31. (in Chinese with English abstract)
URL PMID |
[ 单立山, 李毅, 任伟, 苏世平, 董秋莲, 耿东梅 (2013). 河西走廊中部两种荒漠植物根系构型特征. 应用生态学报, 24,25-31.]
PMID |
|
[25] | Spek LY, van Noordwijk M (1994). Proximal root diameter as predictor of total root size for fractal branching models. Plant and Soil, 164,119-127. |
[26] | Strahler AN (1952). Hypsometric (area altitude) analysis of erosional topography. Geological Society of America Bulletin, 63,1117-1142. |
[27] | Tamang B, Andreu MG, Rockwood DL (2010). Microclimate patterns on the leeside of single-row tree windbreaks during different weather conditions in Florida farms: implications for improved crop production. Agroforestry Systems, 79,111-122. |
[28] |
Thomas CW, Erik VE, Jonathan PL (2004). Modeling applicability of fractal analysis to efficiency of soil exploration by roots. Annals of Botany, 94,119-128.
URL PMID |
[29] | Vercambre G, Pagès L, Doussan C, Habib R (2003). Architectural analysis and synthesis of the plum tree root system in an orchard using a quantitative modelling approach. Plant and Soil, 251,1-11. |
[30] | van Noordwijk M, Purnomosidhi P (1995). Root architecture in relation to tree-soil-crop interactions and shoot pruning in agroforestry. Agroforestry Systems, 30,161-173. |
[31] | Wang XZ, Ge JP (2004). Dynamic changes of the Qira Oasis over a 40 year period. Acta Phytoecologica Sinica, 28,369-375. (in Chinese with English abstract) |
[ 王兮之, 葛剑平 (2004). 40多年来塔南策勒绿洲动态变化研究. 植物生态学报, 28,369-375.] | |
[32] | Yang XL, Zhang XM, Li YL, Li SC, Sun HL (2008). Analysis of root architecture and root adaptive strategy in the Taklimakan Desert area of China. Journal of Plant Ecology(Chinese Version), 32,1268-1276. (in Chinese with English abstract) |
[ 杨小林, 张希明, 李义玲, 李绍才, 孙海龙 (2008). 塔克拉玛干沙漠腹地3种植物根系构型及其生境适应策略. 植物生态学报, 32,1268-1276.] | |
[33] | Yang XL, Zhang XM, Li YL, Xie TT, Wang WH (2009). Root fractal characteristics at the hinterland of Taklimakan Desert. Arid Land Geography, 32,249-254. (in Chinese with English abstract) |
[ 杨小林, 张希明, 李义玲, 解婷婷, 王伟华 (2009). 塔克拉玛干沙漠腹地几种植物根系分形特征. 干旱区地理, 32,249-254.] | |
[34] | Zeng FJ (1999). The countermeasures of sustainable development in Cele Oasis Ecosystem, Xinjiang. Arid Zone Research, 16,29-34. (in Chinese with English abstract) |
[ 曾凡江 (1999). 策勒绿洲生态系统的可持续发展对策. 干旱区研究, 16,29-34.] | |
[35] | Zeng FJ, Guo HF, Liu B, Zeng J, Zhang XL (2009). Response of ecological properties of roots of Alhagi sparsifolia Shap. seedlings to different irrigation treatments. Arid Zone Research, 26,853-858. (in Chinese with English abstract) |
[ 曾凡江, 郭海峰, 刘波, 曾杰, 张晓蕾 (2009). 疏叶骆驼刺幼苗根系生态学特性对水分处理的响应. 干旱区研究, 26,853-858.] | |
[36] | Zeng FJ, Liu B (2012). Alhagi Roots Ecology. Science Press, Beijing. (in Chinese) |
[ 曾凡江, 刘波 (2012). 骆驼刺根系生态学. 科学出版社, 北京.] | |
[37] | Zhong F, Wang HC, Li JN, Duan ZH (2006). Influence of water-heat condition on distribution of Platycladus orientalis (L.) Franco roots in southern and northern mountains of Lanzhou City. Journal of Desert Research, 26,559-563. (in Chinese with English abstract) |
[ 钟芳, 王红赤, 李俊年, 段争虎 (2006). 兰州市南北两山水热条件对侧柏根系分布的影响. 中国沙漠, 26,559-563.] |
