Characteristics of canopy stomatal conductance of Populus simonii stands with different degradation degrees and its responses to environmental factors

doi:10.17521/cjpe.2023.0106

Abstract

Abstract:

Aims Canopy stomatal conductance (g_s) is an important indicator for measuring canopy atmospheric water vapor exchange. Studying its characteristics and responses to environmental factors could enhance the understanding of canopy water vapor exchange process and the comprehensive mechanism of environmental factors controlling forest canopy. Currently, differences in canopy stomatal conductance characteristics and its responses to environmental factors of the same tree species with different degradation degrees are still unclear.

Methods In the growing-season of 2019 (May-September), four types of Populus simonii stands with different degrees of degradation (non-degraded, mildly degraded, moderately degraded and severely degraded) in Zhangbei County of Bashang Plateau were selected, and thermal diffusion technology (TDP) probes were set to monitor trunk sap flow continuously. Environmental factors such as photosynthetically active radiation (PAR), vapor pressure deficit (VPD), air temperature (T), relative air humidity (RH) and soil water content (SWC) were monitored synchronously to analyze the sap flow rate and canopy stomatal conductance characteristics of P. simonii and their responses to environmental factors.

Important findings (1) The daily variation of sap flow rate in P. simonii showed a single-peak curve, while the g_s showed a double-peak curve. On the monthly scale, both sap flow rate and g_s showed a trend of increasing at first and declining subsequently, and then reaching the highest values in July. The differences in sap flow rate and g_s of P. simonii among the four stands of degradation degrees were significant in May and September. (2) The g_s was all affected by T, VPD and SWC. However, due to the differences in degradation, g_s in the non-degraded stands was mainly affected by T, VPD and 80-160 cm SWC. In the mildly degraded stands g_s was mainly affected by T, 0-80 cm SWC and VPD, and that in the moderately degraded was mainly affected by 0-80 cm SWC, T, VPD, while it in the severely degraded was mainly affected by T, PAR and VPD. (3) For the all P. simonii of different degradation degrees, the g_s above 18 °C was positively correlated with T. At 0.6-2.2 kPa, it was positively correlated with VPD, while negatively correlated with SWC. The g_s of the severely degraded P. simonii was positively correlated PAR when it was below 250 μmol·m^-2·s^-1. (4) Compared to the other three types of P. simonii, the severely degraded one had a more positive response to T changes and a lower sensitivity to other environmental factors. Due to morphological degradation, control of canopy transpiration of the severely degraded P. simonii will be even stricter to avoid further degradation or dieback.

Key words: canopy stomatal conductance, Populus simonii, degradation, environmental response, sap flow

ZHANG Xiao-Yu, JIA Guo-Dong, YU Xin-Xiao, SUN Li-Bo, JIANG Tao. Characteristics of canopy stomatal conductance of Populus simonii stands with different degradation degrees and its responses to environmental factors[J]. Chin J Plant Ecol, 2024, 48(9): 1143-1156.

Add to citation manager EndNote|Ris|BibTeX

URL: https://www.plant-ecology.com/EN/10.17521/cjpe.2023.0106

https://www.plant-ecology.com/EN/Y2024/V48/I9/1143

Figures/Tables 13

References 54

[1]	Anderegg WRL, Klein T, Bartlett M, Sack L, Pellegrini AFA, Choat B, Jansen S (2016). Meta-analysis reveals that hydraulic traits explain cross-species patterns of drought-induced tree mortality across the globe. Proceedings of the National Academy of Sciences of the United States of America, 113, 5024-5029. DOI PMID
[2]	Baheti ZED, Jia GD, Yu XX, Shi JM, Jiang T (2020). Assessing water sources for Populus simonii with different degrees of degradation based on stable isotopes. Chinese Journal of Applied Ecology, 31, 1807-1816.
	[孜尔蝶·巴合提, 贾国栋, 余新晓, 史佳美, 蒋涛 (2020). 基于稳定同位素分析不同退化程度小叶杨水分来源. 应用生态学报, 31, 1807-1816.] DOI
[3]	Bigler C, Bräker OU, Bugmann H, Dobbertin M, Rigling A (2006). Drought as an inciting mortality factor in Scots pine stands of the Valais, Switzerland. Ecosystems, 9, 330-343.
[4]	Cai WH, Yang J, Liu ZH, Hu YM, Liu SJ, Jing GZ, Zhao ZF (2012). Controls of post-fire tree recruitment in Great Xing’an Mountains in Heilongjiang Province. Acta Ecologica Sinica, 32, 3303-3312.
	[蔡文华, 杨健, 刘志华, 胡远满, 柳生吉, 荆国志, 赵增福 (2012). 黑龙江省大兴安岭林区火烧迹地森林更新及其影响因子. 生态学报, 32, 3303-3312.]
[5]	Campbell GS, Norman JM (2000). An Introduction to Environmental Biophysics. Springer, New York.
[6]	Cao QP, Zhao P, Ni GY, Zhu LW, Niu JF, Zeng XP (2013). Responses of canopy stomatal conductance of Schima superba stand to vapor pressure deficient in southern China. Chinese Journal of Ecology, 32, 1770-1779.
	[曹庆平, 赵平, 倪广艳, 朱丽薇, 牛俊峰, 曾小平 (2013). 华南荷木林冠层气孔导度对水汽压亏缺的响应. 生态学杂志, 32, 1770-1779.]
[7]	Chen SN, Chen ZSN, Zhang ZQ (2021). Canopy stomatal conductance characteristics of Pinus tabulaeformis and Acer truncatum and their responses to environmental factors in the mountain area of Beijing. Chinese Journal of Plant Ecology, 45, 1329-1340.
	[陈胜楠, 陈左司南, 张志强 (2021). 北京山区油松和元宝槭冠层气孔导度特征及其环境响应. 植物生态学报, 45, 1329-1340.] DOI
[8]	Dekker SC, Bouten W, Bosveld FC (2001). On the information content of forest transpiration measurements for identifying canopy conductance model parameters. Hydrological Processes, 15, 2821-2832.
[9]	Elith J, Leathwick JR, Hastie T (2008). A working guide to boosted regression trees. Journal of Animal Ecology, 77, 802-813. DOI PMID
[10]	Ewers BE, MacKay DS, Samanta S (2007a). Interannual consistency in canopy stomatal conductance control of leaf water potential across seven tree species. Tree Physiology, 27, 11-24.
[11]	Ewers BE, Oren R, Kim HS, Bohrer G, Lai CT (2007b). Effects of hydraulic architecture and spatial variation in light on mean stomatal conductance of tree branches and crowns. Plant, Cell & Environment, 30, 483-496.
[12]	Fu S, Sun L, Luo Y (2017). Canopy conductance and stand transpiration of Populus simonii Carr. in response to soil and atmospheric water deficits in farmland shelterbelt, Northwest China. Agroforestry Systems, 91, 1165-1180.
[13]	Granier A (1985). A new method of sap flow measurement in tree stems. Annals of Forest Science, 42, 193-200.
[14]	Hu YT, Zhao P, Niu JF, Sun ZW, Zhu LW (2015). Characteristics of canopy stomatal conductance in plantations of three re-vegetation tree species and its sensitivity to environmental factors. Chinese Journal of Applied Ecology, 26, 2623-2631.
	[胡彦婷, 赵平, 牛俊峰, 孙振伟, 朱丽薇 (2015). 三种植被恢复树种的冠层气孔导度特征及其对环境因子的敏感性. 应用生态学报, 26, 2623-2631.]
[15]	Huang YQ, Li XK, Zhang ZF, He CX, Zhao P, You YM, Mo L (2011). Seasonal changes in Cyclobalanopsis glauca transpiration and canopy stomatal conductance and their dependence on subterranean water and climatic factors in rocky karst terrain. Journal of Hydrology, 402, 135-143.
[16]	Jia JB (2016). Water Movement Process and Mechanism Analysis on Forest Ecosystems in Beijing Mountainous area. PhD dissertation, Beijing Forestry University, Beijing.
	[贾剑波 (2016). 北京山区典型森林生态系统水分运动过程与机制研究. 博士学位论文, 北京林业大学, 北京.]
[17]	Jiao LL, Chang Y, Shen D, Hu YM, Li CL, Ma J (2015). Using boosted regression trees to analyze the factors affecting the spatial distribution pattern of wildfire in China. Chinese Journal of Ecology, 34, 2288-2296.
	[焦琳琳, 常禹, 申丹, 胡远满, 李春林, 马俊 (2015). 利用增强回归树分析中国野火空间分布格局的影响因素. 生态学杂志, 34, 2288-2296.]
[18]	Komatsu H, Onozawa Y, Kume T, Tsuruta K, Shinohara Y, Otsuki K (2012). Canopy conductance for a Moso bamboo (Phyllostachys pubescens) forest in western Japan. Agricultural and Forest Meteorology, 156, 111-120.
[19]	Li CL, Liu M, Hu YM, Xu YY, Sun FY (2014). Driving forces analysis of urban expansion based on boosted regression trees and Logistic regression. Acta Ecologica Sinica, 34, 727-737.
	[李春林, 刘淼, 胡远满, 徐岩岩, 孙凤云 (2014). 基于增强回归树和Logistic回归的城市扩展驱动力分析. 生态学报, 34, 727-737.]
[20]	Li Z, Niu LH, Yuan FH, Guan DX, Wang AZ, Jin CJ, Wu JB (2012). Canopy conductance characteristics of poplar in agroforestry system in West Liaoning Province of Northeast China. Chinese Journal of Applied Ecology, 23, 2975-2982.
	[李峥, 牛丽华, 袁凤辉, 关德新, 王安志, 金昌杰, 吴家兵 (2012). 辽西农林复合系统中杨树冠层导度特征. 应用生态学报, 23, 2975-2982.]
[21]	Liu WN, Jia JB, Yu XX, Jia GD, Hou GR (2017). Characteristics of canopy stomatal conductance of Platycladus orientalis and its responses to environmental factors in the mountainous area of North China. Chinese Journal of Applied Ecology, 28, 3217-3226.
	[刘文娜, 贾剑波, 余新晓, 贾国栋, 侯贵荣 (2017). 华北山区侧柏冠层气孔导度特征及其对环境因子的响应. 应用生态学报, 28, 3217-3226.] DOI
[22]	Liu ZH, Jia GD, Yu XX, Lu WW, Sun LB, Wang YS, Baheti Z (2021). Morphological trait as a determining factor for Populus simonii Carr. to survive from drought in semi-arid region. Agricultural Water Management, 253, 106943. DOI: 10.1016/j.agwat.2021.106943.
[23]	Luo DD (2017). Water Regulation Strategies for 8 Tree Species in the Temperate Forest of Northeastern China. Master degree dissertation, Northeast Forestry University, Harbin.
	[罗丹丹 (2017). 东北温带森林8种树种水分调节对策研究. 硕士学位论文, 东北林业大学, 哈尔滨.]
[24]	Luo ZD, Guan HD, Zhang XP, Liu N, Zhang CC, Wang T (2016). Optimization of canopy stomatal conductance models for Osmanthus fragrans and analysis of its parameters. Acta Ecologica Sinica, 36, 3995-4005.
	[罗紫东, 关华德, 章新平, 刘娜, 张赐成, 王婷 (2016). 桂花树冠层气孔导度模型的优化及其参数分析. 生态学报, 36, 3995-4005.]
[25]	Mayr S, Wieser G, Bauer H (2006). Xylem temperatures during winter in conifers at the alpine timberline. Agricultural and Forest Meteorology, 137, 81-88.
[26]	Medlyn BE, Dreyer E, Ellsworth D, Forstreuter M, Harley PC, Kirschbaum MUF, Le Roux X, Montpied P, Strassemeyer J, Walcroft A, Wang K, Loustau D (2002). Temperature response of parameters of a biochemically based model of photosynthesis. II. A review of experimental data. Plant, Cell & Environment, 25, 1167-1179.
[27]	Miao B, Meng P, Zhang JS, He FJ, Sun SJ (2017). Difference of water relationships of poplar trees in Zhangbei County, Hebei, China based on stable isotope and thermal dissipation method. Chinese Journal of Applied Ecology, 28, 2111-2118. DOI
	[苗博, 孟平, 张劲松, 何方杰, 孙守家 (2017). 基于稳定同位素和热扩散技术的张北杨树水分关系差异. 应用生态学报, 28, 2111-2118.] DOI
[28]	Oren R, Sperry JS, Ewers BE, Pataki DE, Phillips N, Megonigal JP (2001). Sensitivity of mean canopy stomatal conductance to vapor pressure deficit in a flooded Taxodium distichum L. forest: hydraulic and non-hydraulic effects. Oecologia, 126, 21-29. DOI PMID
[29]	Peltier DMP, Barber JJ, Ogle K (2018). Quantifying antecedent climatic drivers of tree growth in the Southwestern US. Journal of Ecology, 106, 613-624.
[30]	Qu BL, Guo YP, Yang JW, Lü KL, Ma CM (2020). Characteristics of sap flow in fast-growing poplar and its response to driving factors in the central Hebei plain. Journal of Northeast Forestry University, 48(12), 18-22.
	[屈柏林, 郭延朋, 杨晶雯, 吕康乐, 马长明 (2020). 冀中平原速生杨树干液流特征及驱动因子对其影响. 东北林业大学学报, 48(12), 18-22.]
[31]	Rodrigues TR, Vourlitis GL, de A Lobo F, Oliveira RG, de S Nogueira J(2014). Seasonal variation in energy balance and canopy conductance for a tropical savanna ecosystem of south central Mato Grosso, Brazil. Journal of Geophysical Research: Biogeosciences, 119, 1-13.
[32]	Ripullone F, Camarero JJ, Colangelo M, Voltas J (2020). Variation in the access to deep soil water pools explains tree-to-tree differences in drought-triggered dieback of Mediterranean oaks. Tree Physiology, 40, 591-604. DOI PMID
[33]	Song LN, Zhu JJ, Zhang T, Wang K, Wang GC, Liu JH (2021). Higher canopy transpiration rates induced dieback in poplar (Populus × xiaozhuanica) plantations in a semiarid sandy region of Northeast China. Agricultural Water Management, 243, 106414. DOI: 10.1016/j.agwat.2020.106414.
[34]	Sun L, Guan W, Wang YH, Xu LH, Xiong W (2011). Simulations of Larix principis-rupprechtii stand mean canopy stomatal conductance and its responses to environmental factors. Chinese Journal of Ecology, 30, 2122-2128.
	[孙林, 管伟, 王彦辉, 徐丽宏, 熊伟 (2011). 华北落叶松冠层平均气孔导度模拟及其对环境因子的响应. 生态学杂志, 30, 2122-2128.]
[35]	Sun LB, Chang XM, Yu XX, Jia GD, Chen LH, Wang YS, Liu ZQ (2021). Effect of freeze-thaw processes on soil water transport of farmland in a semi-arid area. Agricultural Water Management, 252, 106876. DOI: 10.1016/j.agwat.2021.106876.
[36]	Serra-Maluquer X, Granda E, Camarero JJ, Vilὰ-Cabrera A, Jump AS, Sάnchez-Salguero R, Sangüesa-Barreda G, Imbert JB, Gazol A, Jucker T (2021). Impacts of recurrent dry and wet years alter long-term tree growth trajectories. Journal of Ecology, 109(3), 1561-1574.
[37]	Voltas J, Camarero JJ, Carulla D, Aguilera M, Ortiz A, Ferrio JP (2013). A retrospective, dual-isotope approach reveals individual predispositions to winter-drought induced tree dieback in the southernmost distribution limit of Scots pine. Plant, Cell & Environment, 36, 1435-1448.
[38]	Wang Y, Liu MJ, Guo HN, Du S (2023). Canopy stomatal conductance of Robinia pseudoacacia under rainfall exclusion treatment. Research of Soil and Water Conservation, 30(5), 209-216.
	[王瑛, 刘美君, 郭海宁, 杜盛 (2023). 减雨处理环境下刺槐冠层气孔导度变化特征. 水土保持研究, 30(5), 209-216.]
[39]	Whitley R, Medlyn B, Zeppel M, Macinnis-Ng C, Eamus D (2009). Comparing the Penman-Monteith equation and a modified Jarvis-Stewart model with an artificial neural network to estimate stand-scale transpiration and canopy conductance. Journal of Hydrology, 373, 256-266.
[40]	Wu JJ, Qiu YX, Wang YS, Yu XX, Chen LH, Jia GD, Qiu GF (2021). Fine roots distribution characteristics of Populus simonii with different degradation degrees in Bashang area. Journal of Soil and Water Conservation, 35(5), 242-248.
	[武娟娟, 邱云霄, 王渝淞, 余新晓, 陈丽华, 贾国栋, 邱贵福 (2021). 坝上地区不同退化程度小叶杨细根分布特征. 水土保持学报, 35(5), 242-248.]
[41]	Wu RQ, Jia JB, Yan WD, Hu L, Wang YF, Chen Y (2022). Characteristics of canopy conductance and environmental driving mechanism in three monsoon climate regions of China. Frontiers in Environmental Science, 10, 935926. DOI: 10.3389/fenvs.2022.935926.
[42]	Xu H, Li ML, Liang HB, Li ZS, Wu X (2018). Review of the evaluation index system for degraded forest ecosystems. Acta Ecologica Sinica, 38, 9034-9042.
	[徐欢, 李美丽, 梁海斌, 李宗善, 伍星 (2018). 退化森林生态系统评价指标体系研究进展. 生态学报, 38, 9034-9042.]
[43]	Xu WT, Zhao P, Wang Q, Rao XQ, Cai XA, Zeng XP (2007). Calculation and modeling of the canopy stomatal conductance of Acacia mangium from sap flow data. Acta Ecologica Sinica, 27, 4122-4131.
	[许文滔, 赵平, 王权, 饶兴权, 蔡锡安, 曾小平 (2007). 基于树干液流测定值的马占相思(Acacia mangium)冠层气孔导度计算及数值模拟. 生态学报, 27, 4122-4131.]
[44]	Yan CZ, Zheng WG, Jia JB, Yan WD, Wang ZC, Jia GD (2020). Responses of canopy stomatal conductance of Platycladus orientalis to soil water under water control. Chinese Journal of Applied Ecology, 31, 4017-4026.
	[颜成正, 郑文革, 贾剑波, 闫文德, 王忠诚, 贾国栋 (2020). 控水条件下侧柏冠层气孔导度对土壤水的响应. 应用生态学报, 31, 4017-4026.] DOI
[45]	Yoshida M, Ohta T, Kotani A, Maximov T (2010). Environmental factors controlling forest evapotranspiration and surface conductance on a multi-temporal scale in growing seasons of a Siberian larch forest. Journal of Hydrology, 395, 180-189.
[46]	Yoshifuji N, Kumagai T, Ichie T, Kume T, Tateishi M, Inoue Y, Yoneyama A, Nakashizuka T (2020). Limited stomatal regulation of the largest-size class of Dryobalanops aromatica in a Bornean tropical rainforest in response to artificial soil moisture reduction. Journal of Plant Research, 133, 175-191. DOI PMID
[47]	Yu TF, Feng Q, Si JH (2012). Simulating responses of leaf stomatal conductance to environmental factors for Tamarix ramosissma in an extreme arid region of China. Chinese Journal of Plant Ecology, 36, 483-490.
	[鱼腾飞, 冯起, 司建华 (2012). 极端干旱区多枝柽柳叶片气孔导度的环境响应模拟. 植物生态学报, 36, 483-490.] DOI
[48]	Zhang H, Cao J, Wang HB, Song B, Jia GD, Liu ZQ, Yu XX, Zeng J (2018). Water utilization characteristics of the degraded poplar shelterbelts in Zhangbei, Hebei, China. Chinese Journal of Applied Ecology, 29, 1381-1388. DOI
	[张欢, 曹俊, 王化冰, 宋波, 贾国栋, 刘自强, 余新晓, 曾佳 (2018). 张北地区退化杨树防护林的水分利用特征. 应用生态学报, 29, 1381-1388.] DOI
[49]	Zhang Z, Xin XZ, Yi CX, Peng ZQ, Liu QH (2021). Advanced model of canopy stomatal conductance considering vegetation types. Transactions of the Chinese Society of Agricultural Engineering, 37(3), 164-172.
	[张振, 辛晓洲, 裔传祥, 彭志晴, 柳钦火 (2021). 考虑植被类型的冠层气孔导度模型. 农业工程学报, 37(3), 164-172.]
[50]	Zhao P, Ma L, Sun GC, Rao XQ, Cai XA, Zeng XP (2005). The carbon assimilation rate of forest was determined by canopy stomatal conductance and ¹³C discrimination rate based on sap flow. Chinese Science Bulletin, 50, 1620-1626.
	[赵平, 马玲, 孙谷畴, 饶兴权, 蔡锡安, 曾小平 (2005). 利用基于sap flow测定值的冠层气孔导度和¹³C甄别率测定森林的碳同化率. 科学通报, 50, 1620-1626.]
[51]	Zhao P, Rao XQ, Ma L, Cai XA, Zeng XP (2006). Responses of canopy stomatal conductance of Acacia mangium forest to environmental driving factors. Chinese Journal of Applied Ecology, 17, 1149-1156.
	[赵平, 饶兴权, 马玲, 蔡锡安, 曾小平 (2006). 马占相思林冠层气孔导度对环境驱动因子的响应. 应用生态学报, 17, 1149-1156.]
[52]	Zhao P, Xu XY, Jiang SX, Xu GX, Chai CW, Zhang YJ, Ma YL, Qi FJ, Gao DC, Zhang GP (2022). Water utilization pattern of Tamarix ramosissima Ledeb. Nebkhas with different decline degrees in the lower reaches of Shiyang River. Acta Ecologica Sinica, 42, 7187-7197.
	[赵鹏, 徐先英, 姜生秀, 徐高兴, 柴成武, 张逸君, 马玉莲, 戚福俊, 高德才, 张国平 (2022). 石羊河下游不同衰退程度多枝柽柳灌丛水分利用格局研究. 生态学报, 42, 7187-7197.]
[53]	Zhu HY, Li HY, Wang XL, Jiang T, Sun L, Luo Y (2022). Characteristics and modeling of canopy stomatal conductance and transpiration of Pinus tabuliformis on the Loess Plateau. Acta Ecologica Sinica, 42, 9130-9142.
	[朱昊阳, 李洪宇, 王晓蕾, 姜婷, 孙林, 罗毅 (2022). 黄土高原油松冠层气孔导度和蒸腾变化特征与模拟. 生态学报, 42, 9130-9142.]
[54]	Zhu LW, Zhao P, Cai XA, Zou XP, Zou L, Quan W (2010). Characteristics of transpiration and canopy stomatal conductance of Schima superba plantation and their responses to environmental factors. Journal of Tropical and Subtropical Botany, 18, 599-606.

编号Number	人工林退化程度 Degradation degree of stand	树高 Tree height (m)	胸径 Diameter at breast height (cm)	冠幅 Crown diameter (m)
编号Number	人工林退化程度 Degradation degree of stand	树高 Tree height (m)	胸径 Diameter at breast height (cm)	东西 East-west	南北 South-north
1	无退化 Non-degradation	14.3	32.0	6.7	5.3
2	无退化 Non-degradation	14.2	23.5	4.1	2.1
3	无退化 Non-degradation	13.5	24.2	6.5	5.2
4	轻度退化 Mild degradation	14.2	23.5	2.8	3.5
5	轻度退化 Mild degradation	13.7	26.0	3.5	2.5
6	轻度退化 Mild degradation	13.4	24.2	2.8	3.5
7	中度退化 Moderate degradation	12.6	21.8	2.8	3.1
8	中度退化 Moderate degradation	11.1	16.2	2.2	3.5
9	中度退化 Moderate degradation	12.9	23.7	2.2	3.5
10	重度退化 Severe degradation	13.7	41.0	6.7	5.3
11	重度退化 Severe degradation	10.6	18.5	6.5	5.1
12	重度退化 Severe degradation	12.9	23.7	6.4	5.3

编号Number	人工林退化程度 Degradation degree of stand	树高 Tree height (m)	胸径 Diameter at breast height (cm)	冠幅 Crown diameter (m)
编号Number	人工林退化程度 Degradation degree of stand	树高 Tree height (m)	胸径 Diameter at breast height (cm)	东西 East-west	南北 South-north
1	无退化 Non-degradation	14.3	32.0	6.7	5.3
2	无退化 Non-degradation	14.2	23.5	4.1	2.1
3	无退化 Non-degradation	13.5	24.2	6.5	5.2
4	轻度退化 Mild degradation	14.2	23.5	2.8	3.5
5	轻度退化 Mild degradation	13.7	26.0	3.5	2.5
6	轻度退化 Mild degradation	13.4	24.2	2.8	3.5
7	中度退化 Moderate degradation	12.6	21.8	2.8	3.1
8	中度退化 Moderate degradation	11.1	16.2	2.2	3.5
9	中度退化 Moderate degradation	12.9	23.7	2.2	3.5
10	重度退化 Severe degradation	13.7	41.0	6.7	5.3
11	重度退化 Severe degradation	10.6	18.5	6.5	5.1
12	重度退化 Severe degradation	12.9	23.7	6.4	5.3

月份 Month	无退化 Non-degradation	轻度退化 Mild degradation	中度退化 Moderate degradation	重度退化 Severe degradation
5月 May	43.54 ± 3.90^b	31.52 ± 3.13^bc	17.65 ± 2.05^c	80.71 ± 8.36^a
6月 June	114.75 ± 12.40^a	67.25 ± 8.67^b	54.39 ± 6.09^b	47.64 ± 4.68^b
7月 July	151.60 ± 18.19^a	100.48 ± 13.22^b	68.15 ± 8.39^bc	43.83 ± 4.80^c
8月 August	119.25 ± 14.83^a	54.28 ± 7.14^b	41.57 ± 5.29^b	35.91 ± 4.17^b
9月 September	48.37 ± 6.25^a	10.15 ± 1.16^b	9.39 ± 1.22^b	4.85 ± 0.61^b

月份 Month	无退化 Non-degradation	轻度退化 Mild degradation	中度退化 Moderate degradation	重度退化 Severe degradation
5月 May	43.54 ± 3.90^b	31.52 ± 3.13^bc	17.65 ± 2.05^c	80.71 ± 8.36^a
6月 June	114.75 ± 12.40^a	67.25 ± 8.67^b	54.39 ± 6.09^b	47.64 ± 4.68^b
7月 July	151.60 ± 18.19^a	100.48 ± 13.22^b	68.15 ± 8.39^bc	43.83 ± 4.80^c
8月 August	119.25 ± 14.83^a	54.28 ± 7.14^b	41.57 ± 5.29^b	35.91 ± 4.17^b
9月 September	48.37 ± 6.25^a	10.15 ± 1.16^b	9.39 ± 1.22^b	4.85 ± 0.61^b

月份 Month	无退化 Non-degradation	轻度退化 Mild degradation	中度退化 Moderate degradation	重度退化 Severe degradation
5月 May	0.077 ± 0.008 4^b	0.106 ± 0.011 0^b	0.070 ± 0.007 8^b	0.220 ± 0.021 0^a
6月 June	0.297 ± 0.039 7^ab	0.337 ± 0.045 0^a	0.219 ± 0.033 7^b	0.213 ± 0.024 9^b
7月 July	0.662 ± 0.102 0^a	0.789 ± 0.102 0^a	0.569 ± 0.072 9^ab	0.367 ± 0.045 2^ab
8月 August	0.372 ± 0.048 0^a	0.265 ± 0.037 2^b	0.242 ± 0.024 6^b	0.255 ± 0.034 0^b
9月 September	0.175 ± 0.014 5^a	0.082 ± 0.006 8^b	0.054 ± 0.007 2^c	0.036 ± 0.006 2^c
