宁夏沙湖4种干旱区群落中主要植物种间关系的格局分析

doi:10.3773/j.issn.1005-264x.2009.02.009

摘要/Abstract

摘要：

格局分析是研究群落结构、种群特征、种内种间关系以及生物与环境间相互作用的重要手段。应用Ripley’s K函数的双变量点格局分析技术, 对宁夏沙湖4种干旱区群落中主要植物种间的空间关联关系进行了研究; 同时, 根据关联物种间相对位置的规则性, 基于Ripley’s K函数, 提出一种用于检测种间格局控制关系的技术方法。研究结果表明: 1) 沙枣(Elaeagnus angustifolia)-芨芨草(Achnatherum splendens)、芨芨草-苦豆子(Sophora alopecuroides)、白刺(Nitraria tangutorum)-芨芨草3个群落中, 主要物种间在个体大小、根系特点和生态习性等方面存在较大的差异, 并分别在一定的尺度范围内存在正关联关系; 而在物种生态需求和形态大小等方面相对一致的红砂(Reaumuria soongorica)-盐爪爪(Kalidium foliatum)群落中, 红砂和盐爪爪之间在整个观测尺度内(0~15 m)存在负关联关系。2) 格局控制分析表明, 在主要物种间存在空间正关联关系的3个群落中, 均检测出主要物种间在一定尺度范围内存在格局控制关系, 其中格局控制种一般个体较大、生境改造能力较强; 而在主要物种生活型相似的红砂-盐爪爪群落中, 未检测到主要物种间的格局控制关系。

关键词: 点格局分析, Ripley’s K函数, 格局控制分析, 种间关系

Abstract:

Aims Inter-specific interactions in plant communities can be characterized by their spatial relationships. Because these interactions are usually asymmetrical, i.e., one species exerts more influences on the other, asymmetric spatial patterns should be expected. Our objective was to study how species spatially adapt to arid conditions in four typical arid communities that differed in growth-form composition (tree-grass, shrub-grass, shrub-semishrub and forb-grass).

Methods We selected four representative arid plant communities near Sand Lake in Xidatan, Pingluo County, Ningxia Hui Autonomous Region and measured the position, height and crown diameter of each individual in a 30 m × 30 m plot in each community. We applied the bivariate Ripley’s K function in spatial association analysis and developed a new method named pattern control analysis (PCA) for investigating asymmetric spatial relationships. PCA was derived from the assumption that the controlled species should be distributed around the controlling species regularly at a specific scale. Two simulated community patterns were used to test the new method.

Important findings In communities ofElaeagnus angustifolia-Achnatherum splendens (EA), Nitraria tangutorum-A. splendens (NA) and A. splendens-Sophora alopecuroides (AS), significant positive spatial associations were detected between the dominant species (at scales of 0-15 m, 0-7.5 m and 0-7 m, respectively), and species pairs with positive spatial association significantly differed with each other in growth form. In the community of Reaumuria soongorica-Kalidium foliatum (RK), negative spatial association was detected (at the scale of <15 m) between the two dominant species, which are similar in growth form. Pattern control analysis showed a relationship between the dominant species in the three communities with positive spatial associations at scales of 0-6.5 m, 0-0.65 m and 0-1.5 m in EA, NA and AS, respectively. The pattern-controlling species in each community are larger in size and produced better developed microhabitats. However, no such relationship was detected between the dominant species of similar growth form and comparable microhabitats in RK. Results indicate that certain spatial relationships, especially pattern-controlling relationships, might be mechanisms for adaptation within plant communities. This might help in understanding inter-specific interactions within plant communities.

Key words: point pattern analysis, Ripley’s K function, pattern control analysis, inter-specific relationship

刘小恺, 刘茂松, 黄峥, 徐驰, 张明娟, 王汉杰. 宁夏沙湖4种干旱区群落中主要植物种间关系的格局分析. 植物生态学报, 2009, 33(2): 320-330. DOI: 10.3773/j.issn.1005-264x.2009.02.009

LIU Xiao-Kai, LIU Mao-Song, HUANG Zheng, XU Chi, ZHANG Min-Juan, WANG Han-Jie. PATTERN ANALYSIS OF INTER-SPECIFIC RELATIONSHIPS IN FOUR ARID COMMUNITIES IN SAND LAKE, NINGXIA HUI AUTONOMOUS REGION, CHINA. Chinese Journal of Plant Ecology, 2009, 33(2): 320-330. DOI: 10.3773/j.issn.1005-264x.2009.02.009

导出引用管理器 EndNote|Ris|BibTeX

链接本文: https://www.plant-ecology.com/CN/10.3773/j.issn.1005-264x.2009.02.009

https://www.plant-ecology.com/CN/Y2009/V33/I2/320

图/表 7

参考文献 42

[1]	Bertness MD, Callaway RM (1994). Positive interactions in communities. Trends in Ecology and Evolution, 9,191-193. DOI URL PMID
[2]	Brown JR, Archer S (1999). Shrub invasion of grassland: recruitment is continuous and not regulated by herbaceous biomass or density. Ecology, 80,2385-2396.
[3]	Callaway RM, Brooker RW, Choler P, Kikvidze Z, Lortie CJ, Michalet R, Paolini L, Pugnaire FI, Newingham B, Aschehoug ET, Armas C, Kikodze D, Cook BJ (2002). Positive interactions among alpine plants increase with stress. Nature, 417,844-848. DOI URL PMID
[4]	Callaway RM, Walker LR (1997). Competition and facilitation: a synthetic approach to interactions in plant communities. Ecology, 78,1958-1965.
[5]	Clark PJ, Evans FC (1954). Distance to nearest neighbor as a measure of spatial relationships in populations. Ecology, 35,445-453.
[6]	Diggle PJ (2003). Statistical Analysis of Spatial Point Patterns 2nd edn. Academic Press, London,UK.
[7]	Dixon P (1994). Testing spatial segregation using a nearestneighbor contingency table. Ecology, 75,1940-1948.
[8]	Eccles NS, Esler KJ, Cowling RM (1999). Spatial pattern analysis in Namaqualand desert plant communities. Plant Ecology, 142,71-85.
[9]	Fan WB (范文波), Lei Y (雷雨), MO L (莫亮), Zheng YK (郑耀凯), Chen B (陈兵), Liu LY (刘丽英) (2006). Studies on improving microclimate of desert by Achnatherum splenden. Journal of Shihezi University(石河子大学学报), 24,213-216. (in Chinese with English abstract)
[10]	Franco AC, Nobel PS (1988). Interactions between seedlings of Agave deserti and the nurse plant Hilaria rigida. Ecology, 69,1731-1740.
[11]	Franco AC, Nobel PS (1989). Effect of nurse plants on the microhabitat and growth of cacti. Journal of Ecology, 77,870-886.
[12]	Franco-Pizana J, Fulbright TE, Gardiner DT (1995). Spatial relations between shrubs and Prosopis glandulosa canopies. Journal of Vegetation Science, 6,73-78.
[13]	Grouzis M, Akpo LE (1997). Influence of tree cover on herbaceous above- and below-ground phytomass in the Sahelian zone of Senegal. Journal of Arid Environments, 35,285-296.
[14]	Gustafson EJ (1998). Quantifying landscape spatial pattern: what is the state of the art? Ecosystems, 1,143-156.
[15]	Hacker SD, Gaines SD (1997). Some implications of direct positive interactions for community species diversity. Ecology, 78,1990-2003.
[16]	Jones CG, Lawton JH, Shachak M (1994). Organisms as ecosystem engineers. Oikos, 69,373-386.
[17]	Jones CG, Lawton JH, Shachak M (1997). Positive and negative effects of organisms as physical ecosystem engineers. Ecology, 78,1946-1957.
[18]	Kenkel NC (1988). Pattern of self-thinning in jack pine: testing the random mortality hypothesis. Ecology, 69,1017-1024.
[19]	Kieft TL, White CS, Loftin SR, Aguilar R, Craig JA, Skaar DA (1998). Temporal dynamics in soil carbon and nitrogen resoures at a grassland-shrubland ecotone. Ecology, 79,671-683.
[20]	LevinSA (1992). The problem of pattern and scale in ecology. Ecology, 73,1943-1967.
[21]	Noble PS (1997). Root distribution and seasonal production in the northwestern Sonoran desert for a C₃ shrub, a C₄ bunchgrass, and a CAM leaf succulent. American Journal of Botany, 84,949-955. URL PMID
[22]	Perry GLW, Miller BP, Enright NJ (2006). A comparison of methods for the statistical analysis of spatial point patterns in plant ecology. Plant Ecology, 187,59-82.
[23]	Pielou EC (1961). Segregation and symmetry in two-species populations as studied in nearest-neighbour relationships. Journal of Ecology, 49,255-269.
[24]	Ripley BD (1977). Modelling spatial pattern. Journal of the Royal Statistical Society, Serues B, 39,17-212.
[25]	Schenk HJ, Holzapfel C, Hamilton JG, Mahall BE (2003). Spatial ecology of a small desert shrub on adjacent geological substrates. Journal of Ecology, 91,383-395.
[26]	Schlesinger WH, Raikes JA, Hartly AE, Cross AF (1996). On the spatial pattern of soil nutrients in desert ecosystems. Ecology, 77,364-374.
[27]	Stoyan D, Penttinen A (2000). Recent applications of point process methods in forestry statistics. Statistical Science, 15,61-78.
[28]	Tang MP (汤孟平), Tang SZ (唐守正), Lei XD (雷相东), Zhang HR (张会儒), Hong LX (洪玲霞), Feng YM (冯益明) (2003). Edge correction of Ripley’s K(d) function on population spatial pattern analysis. Acta Ecologica Sinica (生态学报), 23,1533-1538. (in Chinese with English abstract)
[29]	Tirado R, Pugnaire FI (2005). Community structure and positive interactions in constraining environments. Oikos, 111,437-444.
[30]	Valiente-Banuet A, Bolongaro-Crevenna A, Briones O, Ezcurra E, Rosas M, Nunez H, Barnard G, Vazquez E (1991a). Spatial relationships between cacti and nurse shrubs in a semi-arid environment in central Mexico. Journal of Vegetation Science, 2,15-20.
[31]	Valiente-Banuet A, Ezcurra E (1991b). Shade as a cause of the association between the cactus Neobuxbaumia tetetzo and the nurse plant Mimosa luisiana in the Tehuacan valley. Mexico Journal of Ecology, 79,961-971.
[32]	Wang K (王库), Xu LY (徐礼煜), Yu TF (于天富) (2002). Effect of Achnatherum splendens (Trin.) Nevski, a soil and water conservation plant, on soil nutrients. Soil(土壤), 3,170-172. (in Chinese)
[33]	Wang N (王宁) (2000). Genus Nitraria resources and prospects for its development. Shaanxi Forest Science and Technology (陕西林业科技), 31,17-18. (in Chinese)
[34]	Ward JS, Parker GR, Ferrandino FJ (1996). Long-term spatial dynamics in an old growth deciduous forest. Forest Ecology and Management, 83,189-202.
[35]	Wiegand T, Kissling WD, Cipriotti PA, Aguiar MR (2006). Extending point pattern analysis for objects of finite size and irregular shape. Journal of Ecology, 94,825-837.
[36]	Wiegand T, Moloney TA (2004). Rings, circles, and null-models for point pattern analysis in ecology. Oikos, 104,209-229.
[37]	Wiens JA, Stenseth NC, Van Horne B, Ims RA (1993). Ecological mechanisms and landscape ecology. Oikos, 66,369-380.
[38]	Wilson JB, Agnew ADQ (1992). Positive-feedback switches in plant communities. Advances in Ecological Research, 23,263-336.
[39]	Yang XH (杨洪晓), Zhang JT (张金屯), Wu B (吴波), Li XS (李晓松), Zhang YY (张友炎) (2006). Point pattern analysis of Artemisia ordosica population in the Mu Us sand land. Journal of Plant Ecology (Chinese Version) (植物生态学报), 30,563-570. (in Chinese with English abstract)
[40]	Zhang C (张程), Zhang MJ (张明娟), Xu C (徐驰), Liu MS (刘茂松), Wang HJ (王汉杰), Hu HB (胡海波) (2007). Anlysis of aggregation in desert plant species in Sand Lake, Ningxia Automous Region, China. Journal of Plant Ecology (Chinese Version) (植物生态学报), 31,32-39. (in Chinese with English abstract)
[41]	Zhang JT (张金屯) (1998). Analysis of spatial point pattern for plant species. Acta Phytoecologica Sinica (植物生态学报), 22,344-349. (in Chinese with English abstract)
[42]	Zhang QM (张琴妹), Zhang C (张程), Liu MS (刘茂松), Yu W (郁文), Xu C (徐驰), Wang HJ (王汉杰) (2007). The influences of arboraceous layer on spatial patterns and morphological characteristics of herbaceous layer in an arid plant community. Acta Ecologica Sinica(生态学报), 27,1265-1272. (in Chinese with English abstract)

群落 Community	概况 Basic status
沙枣-芨芨草 Elaeagnus angustifolia- Achnatherum splendens	沙枣为乔木, 平均高度7.78 m, 平均冠幅6.50 m, 冠层投影盖度达38.5%; 芨芨草为禾本科植物, 平均高度0.79 m, 平均冠幅0.63 m。群落中还零星分布有少量的苦豆子、白刺和小芦草等。群落总盖度85.5%。 The average height, crown diameter and canopy coverage of arbor species Elaeagnus angustifolia are 7.78 m, 6.50 m and 38.5%, respectively. Achnatherum splendens is a kind of bunch grass with an average height of 0.79 m and an average crown diameter of 0.63 m. There scatters a small quantity of Sophora alopecuroide,Nitraria tangutorum and Phragmites australi. Total coverage is 85.5%.
芨芨草-苦豆子 Achnatherum splendens- Sophora alopecuroides	芨芨草平均高度1.13 m, 平均冠幅0.79 m。苦豆子为豆科小灌木, 地上部分为一年生, 平均高度0.32 m,平均冠幅0.20 m。群落中还分布少量的白刺、甘草、碱蓬和藜。群落总盖度65.5%。 The average height of Achnatherum splendens is 1.13 m, its average crown diameter is 0.79 m. Sophora alopecuroides is a small leguminous forb with an average height of 0.32 m and an average crown diameter of 0.20 m. There grows a small amount ofNitraria tangutorum, Radix glycyrrhiza, Suaeda glauca and Chenopodium album. Total coverage is 65.5%.
红砂-盐爪爪 Reaumuria soongorica- Kalidium foliatum	红砂为小灌木, 平均高度0.10 m, 平均冠幅0.14 m; 盐爪爪为小半灌木, 平均高度0.06 m, 平均冠幅0.09 m。群落中另有少量白刺、红柳和芨芨草, 群落总盖度54.4%。 Reaumuria soongorica is a kind of undershrubs with an average height of 0.10 m and an average crown diameter of 0.14 m. Kalidium foliatumis also a kind of undershrubs, with an average height of 0.06 m and an average crown diameter of 0.09 m. There grows a small quantity of Nitraria tangutorum, Tamarix ramoswassima and Achnatherum splendens. Total coverage is 85.5%.
白刺-芨芨草 Nitraria tangutorum- Achnatherum splendens	白刺为匍匐性小灌木, 可拦阻并积聚风沙和枯枝叶, 喜沙埋, 埋后枝节生出不定根, 逐渐形成丘状沙堆。该群落中沙包高度一般不超过0.3 m, 沙包的平均直径为2 m; 芨芨草平均高度0.97 m, 平均冠幅0.72 m。群落中还分布有少量红砂、小芦草和藜。群落总盖度25.9%。 Nitraria tangutorumis small prostrate shrub. It can block and accumulate sand and leaf litters, and grows up sandy mounds. Herein, the height of the sandy mounds generally does not exceed 0.3 m, and the average diameter is 2 m. The average height ofA. splendens is 0.97 m, average crown diameter is 0.72 m. This community also have some small amount of Reaumuria soongorica, Phragmites australi and Chenopodium album. Total coverage is 25.9%

群落 Community	概况 Basic status
沙枣-芨芨草 Elaeagnus angustifolia- Achnatherum splendens	沙枣为乔木, 平均高度7.78 m, 平均冠幅6.50 m, 冠层投影盖度达38.5%; 芨芨草为禾本科植物, 平均高度0.79 m, 平均冠幅0.63 m。群落中还零星分布有少量的苦豆子、白刺和小芦草等。群落总盖度85.5%。 The average height, crown diameter and canopy coverage of arbor species Elaeagnus angustifolia are 7.78 m, 6.50 m and 38.5%, respectively. Achnatherum splendens is a kind of bunch grass with an average height of 0.79 m and an average crown diameter of 0.63 m. There scatters a small quantity of Sophora alopecuroide,Nitraria tangutorum and Phragmites australi. Total coverage is 85.5%.
芨芨草-苦豆子 Achnatherum splendens- Sophora alopecuroides	芨芨草平均高度1.13 m, 平均冠幅0.79 m。苦豆子为豆科小灌木, 地上部分为一年生, 平均高度0.32 m,平均冠幅0.20 m。群落中还分布少量的白刺、甘草、碱蓬和藜。群落总盖度65.5%。 The average height of Achnatherum splendens is 1.13 m, its average crown diameter is 0.79 m. Sophora alopecuroides is a small leguminous forb with an average height of 0.32 m and an average crown diameter of 0.20 m. There grows a small amount ofNitraria tangutorum, Radix glycyrrhiza, Suaeda glauca and Chenopodium album. Total coverage is 65.5%.
红砂-盐爪爪 Reaumuria soongorica- Kalidium foliatum	红砂为小灌木, 平均高度0.10 m, 平均冠幅0.14 m; 盐爪爪为小半灌木, 平均高度0.06 m, 平均冠幅0.09 m。群落中另有少量白刺、红柳和芨芨草, 群落总盖度54.4%。 Reaumuria soongorica is a kind of undershrubs with an average height of 0.10 m and an average crown diameter of 0.14 m. Kalidium foliatumis also a kind of undershrubs, with an average height of 0.06 m and an average crown diameter of 0.09 m. There grows a small quantity of Nitraria tangutorum, Tamarix ramoswassima and Achnatherum splendens. Total coverage is 85.5%.
白刺-芨芨草 Nitraria tangutorum- Achnatherum splendens	白刺为匍匐性小灌木, 可拦阻并积聚风沙和枯枝叶, 喜沙埋, 埋后枝节生出不定根, 逐渐形成丘状沙堆。该群落中沙包高度一般不超过0.3 m, 沙包的平均直径为2 m; 芨芨草平均高度0.97 m, 平均冠幅0.72 m。群落中还分布有少量红砂、小芦草和藜。群落总盖度25.9%。 Nitraria tangutorumis small prostrate shrub. It can block and accumulate sand and leaf litters, and grows up sandy mounds. Herein, the height of the sandy mounds generally does not exceed 0.3 m, and the average diameter is 2 m. The average height ofA. splendens is 0.97 m, average crown diameter is 0.72 m. This community also have some small amount of Reaumuria soongorica, Phragmites australi and Chenopodium album. Total coverage is 25.9%
