五种C4荒漠植物光合器官中含晶细胞的比较分析

doi:10.3773/j.issn.1005-264x.2008.04.016

摘要/Abstract

摘要：

为了探讨荒漠植物适应干旱环境的机理, 选择光合器官发生很大变化的5种C₄荒漠植物进行了解剖结构的对比研究。结果表明, 这5种植物中含晶细胞的数量、大小、形态和分布位置等存在差异。白梭梭(Haloxylon persicum)和梭梭(H. ammodendron)的同化枝普遍具有含晶细胞; 沙拐枣(Calligonum mongolicum)的含晶细胞很少, 一般只分布在贮水组织或靠近栅栏组织处; 木本猪毛菜(Salsola arbuscula)的含晶细胞也不多, 主要分布在栅栏组织和表皮细胞之间; 猪毛菜(S. collina)的含晶细胞更少, 仅在贮水组织中偶尔可见晶簇。比较梭梭、白梭梭和沙拐枣同化枝不同部位的解剖结构发现, 梭梭同化枝基部含晶细胞最多, 中部次之, 顶部最少; 白梭梭同化枝顶部的含晶细胞数量较多, 中部及基部较少; 沙拐枣同化枝顶部与基部的粘液细胞较多, 中部较少, 基部几乎没有栅栏组织, 而其维管组织较为发达。综合晶体的酸碱溶解性及硝酸银组化分析结果, 并参照能谱仪的分析结果得知, 梭梭、白梭梭、沙拐枣和木本猪毛菜的叶片或同化枝中所含晶体的主要成分为草酸钙。通过比较解剖结构发现, 梭梭和白梭梭的同化枝中含晶细胞最多, 其它3种植物的同化器官中含晶细胞较少, 而沙拐枣同化枝中有粘液细胞存在。

关键词: 荒漠植物, 花环状结构, 含晶细胞, 白梭梭, 梭梭, 沙拐枣, 木本猪毛菜, 猪毛菜

Abstract:

Aims Tissue cells that are specialized to produce crystals are referred to as crystal idioblasts. Crystal composition is predominantly calcium oxalate. Calcium oxalate crystal formation in plants appears to play a central role in a variety of important functions. Our aims are to study the occurrence, structures and functions of crystal idioblasts in C₄desert plants and assess the significance of crystal idioblasts in their drought resistance.

Methods We selected five C₄desert plants whose photosynthetic organs are greatly deformed in appearance and structure. We investigated anatomical structures in desert plants Salsola collinaandS. arbuscula and compared differences of assimilating shoots among Haloxylon ammodendron, H. persicum and Calligonum mongolicum using light microscopy. We identified crystals by using histochemical method and energy dispersive spectroscopy (EDS) and observed crystal microstructures under a scanning electron microscope.

Important findings Crystal idioblasts exist in all five species, but there are differences in their distribution, position, amount, size and configuration. Haloxylon persicumand H.ammodendronhave the most crystal idioblasts. Salsola arbusculahas fewer crystals existing between palisade tissues and epidermal cells. The fewest crystals exist in the water-storage tissue ofS. collina. The crystals are in the water-storage tissue or near the palisade tissue in Calligonum mongolicum. The study of different parts of assimilating shoots among H.ammodendron, H. persicum and C.mongolicum shows that in H.ammodendron the base has the most crystals, fewer in middle, least in top; in H. persicum the top of assimilating shoots has the most crystals, fewer in middle and base; there are more mucilage cells in top and base ofC.mongolicum and fewer in middle; the base has few palisade tissue cells but developed vascular tissues. Histochemical and EDS results indicated that crystal nature of H.ammodendron, H. persicum, C.mongolicum and S.arbusculais calcium oxalate. Among the five plants, H. persicumand H.ammodendronhave the most crystal idioblasts, but there are mucilage cells in assimilating shoots of C.mongolicum.

Key words: desert plant, Kranze anatomy, crystal idioblast, Haloxylon persicum, Haloxylon ammodendron, Calligonum mongolicum, Salsola arbuscula, Salsola collina

严巧娣, 苏培玺, 陈宏彬, 张岭梅. 五种C₄荒漠植物光合器官中含晶细胞的比较分析. 植物生态学报, 2008, 32(4): 873-882. DOI: 10.3773/j.issn.1005-264x.2008.04.016

YAN Qiao-Di, SU Pei-Xi, CHEN Hong-Bin, ZHANG Ling-Mei. COMPARATIVE STUDIES ON CRYSTAL IDIOBLASTS OF FIVE DESERT C₄ PLANTS. Chinese Journal of Plant Ecology, 2008, 32(4): 873-882. DOI: 10.3773/j.issn.1005-264x.2008.04.016

导出引用管理器 EndNote|Ris|BibTeX

链接本文: https://www.plant-ecology.com/CN/10.3773/j.issn.1005-264x.2008.04.016

https://www.plant-ecology.com/CN/Y2008/V32/I4/873

图/表 7

表1 5种荒漠植物的采样时间和地点

Table 1 The sampling time and sites of five desert plants

植物 Plant species	采样时间 Sampling time	采集地 Locality
梭梭 Haloxylon ammodendron	2005年8月13日 Aug. 13, 2005	临泽内陆河流域研究站 Linze Inland River Basin Research Station (39°21′02″ N, 100°07′42″ E, altitude 1 370 m)
白梭梭 H. persicum	2005年8月13日 Aug. 13, 2005	临泽内陆河流域研究站 Linze Inland River Basin Research Station (39°21′02″ N, 100°07′42″ E, altitude 1 370 m)
沙拐枣 Calligonum mongolicum	2005年8月13日 Aug. 13, 2005	临泽内陆河流域研究站 Linze Inland River Basin Research Station (39°21′02″ N, 100°07′42″ E, altitude 1 370 m)
猪毛菜 Salsola collina	2005年8月31日 Aug. 31, 2005	临泽北戈壁Gobi desert in the north of Linze (39°07′55″ N, 100°24′22″ E, altitude 1 410 m)
木本猪毛菜 S. arbuscula	2005年8月31日 Aug. 31, 2005	嘉峪关以西戈壁 Gobi desert in the west of Jiayuguan (39°47′22″ N, 98°09′07″ E, altitude 1 760 m)

图1 猪毛菜和木本猪毛菜叶的横截面 a: 猪毛菜 S. collina c: 木本猪毛菜 S. arbuscula b、d: 分别为a和c的局部放大 Partial magnification of a and c, respectively BS: 维管束鞘细胞 Bundle sheath cells CI: 含晶细胞 Crystal idioblast EH: 表皮毛 Epidermal hairs P: 栅栏组织 Palisade tissue VB: 维管束 Vascular bundle WS: 贮水组织 Water storage tissue

Fig. 1 Transverse sections of leaves of Salsola collina and S. arbuscula

图2 梭梭同化枝不同部位横截面 a: 顶部 Top parts b: 中部 Middle parts c: 基部 Basal parts d: b的局部放大 Partial magnification of b BS、CI、P、VB、WS: 见图1 See Fig. 1

Fig. 2 Transverse sections of different parts of assimilating shoots of Haloxylon ammodendron

图3 白梭梭同化枝不同部位横截面 a: 顶部 Top parts b: 中部 Middle parts c: 基部 Basal parts d、e、f: a、b和c的局部放大图 Magnification of partial sections of a, b and c, respectively F: 纤维细胞 Fiber cell BS、CI、P、VB、WS: 见图1 See Fig. 1

Fig. 3 Transverse sections of different parts of assimilating shoots of Haloxylon persicum

图4 沙拐枣同化枝不同部位横截面 a: 顶部 Top parts b: 中部 Middle parts c: 基部 Basal parts d、e: a和b的局部放大图 Partial magnification of a and b, respectively

Fig. 4 Transverse sections of different parts of assimilating shoots of Calligonum mongolicum

图5 梭梭、白梭梭和沙拐枣同化枝的横截面在扫描电镜下的图像 a: 梭梭 Haloxylon ammodendron b: 白梭梭 H. persicum c: 沙拐枣 Calligonum mongolicum d、e、f: a、b和c的局部放大图像 Magnification of partial sections of a, b and c, respectively C：晶体 Crystal P、WS：见图1 See Fig.1

Fig. 5 Scanning electron microscopy photographs of transverse sections of the assimilating shoots of Haloxylon ammodendron, H. persicum and Calligonum mongolicum

图6 木本猪毛菜的叶以及梭梭、白梭梭和沙拐枣的同化枝的横截面切片经AgNO3处理后的图像 a: 木本猪毛菜 S.arbuscula b: 梭梭 H. ammodendron c: 白梭梭 H. persicum d: 沙拐枣 C. mongolicum

Fig. 6 Transverse sections of leaves of Salsola arbuscula and assimilating shoots of Haloxylon ammodendron, H. persicumand Calligonum mongolicum after AgNO3 treatment

参考文献 25

[1]	Cao YZ (曹仪植), Song ZW (宋占午) (1998). Plant Physiology (植物生理学) 1st edn. Lanzhou University Press, Lanzhou,122-143. (in Chinese)
[2]	Choi YE, Harada E, Wada M, Tsuboi H, Morita Y, Kusano T, Sano H (2001). Detoxification of cadmium in tobacco plants: formation and active excretion of crystals containing cadmium and calcium through trichomes. Planta, 213,45-50. URL PMID
[3]	Dijkshoorn W (1973). Organic acids and their role in ion uptake. In: Butler GW, Bailey RW eds. Chemistry and Biochemistry of Herbage, Vol.2. Academic Press, New York,63-187.
[4]	Dobbs FC, Zimmerman RC, Drake LA (2004). Occurrence of intracellular crystals in leaves of Thalassia testudinum . Aquatic Botany, 80,23-28.
[5]	Dong ZY (董占元), Yao YF (姚云峰), Zhao JR (赵金仁), Jia ZC (贾志成) (2000). Anatomical observations on the photosynthetic branch of Haloxylon ammodendrom (C. A. Mey) Bunge and it is the character of drought and salt resistance. Journal of Arid Land Resources and Environment (干旱区资源与环境), 14 (Suppl.),78-83. (in Chinese with English abstract)
[6]	Finley DS (1999). Patterns of calcium oxalate crystals in young tropical leaves: a possible role as an anti-herbivory defense. Revista de Biologia Tropical, 47,27-31.
[7]	Foster AS (1956). Plant idioblasts: remarkable examples of cell particles from photosynthetic tissue. Ⅱ. Oxidative decarboxylation of oxalic acid. Physiologia Plantarum, 7,614-624.
[8]	Franceschi VR (2001). Calcium oxalate in plants. Trends in Plant Science, 6,331.
[9]	Franceschi VR, Horner HT (1980). Calcium oxalate crystals in plants. The Botanical Review, 46,361-427.
[10]	Li ZL (李正理), Li RA (李荣敖) (1981). Anatomical observation of assimilating branches of nine xerophytes in Gansu. Acta Botanica Sinica (植物学报), 23,181-185. (in Chinese with English abstract)
[11]	Liu JQ (刘家琼) (1982). The xeromorphic structure of different typical plants in deserts of China. Acta Phytoecologica et Geobotanica Sinica (植物生态学与地植物学丛刊), 6,314-319. (in Chinese with English abstract)
[12]	Nakata PA (2003). Advances in our understanding of calcium oxalate crystal formation and function in plants. Plant Science, 164,901-909.
[13]	Pizzolato P (1964). Histochemical recognition of calcium oxalate. Journal of Histochemistry and Cytochemistry, 12,333-336.
[14]	Pyankov VI, Black CC, Artyusheva EG, Voznesenskaya EV, Ku MSB, Edwards GE (1999). Features of photosynthesis in Haloxylon species of Chenopodiaceae that are dominant plants in central Asian deserts . Plant & Cell Physiology, 40,125-134.
[15]	Su PX (苏培玺), An LZ (安黎哲), Ma RJ (马瑞君), Liu XM (刘新民) (2005). Kranz anatomy and C₄ photosynthetic characteristics of two desert plants , Haloxylon ammodendron and Calligonum mongolicum. Acta Phytoecologica Sinica (植物生态学报), 29,1-7. (in Chinese with English abstract)
[16]	Su PX, Liu XM, Zhang LX, Zhao AF, Li WR, Chen HS (2004). Comparison of δ¹³C values and gas exchange of assimilating shoots of desert plants Haloxylon ammodendron and Calligonum mongolicum with other plants . Israel Journal of Plant Sciences, 52,87-97.
[17]	Sugimura Y, Mori T, Nitta I, Kotani E, Furusawa T, Tatsumi M, Kusakari SI, Wada M, Morita Y (1999). Calcium deposition in idioblasts of mulberry leaves. Annals of Botany, 83,543-550.
[18]	Volk GM, Lynch-Holm VJ, Kostman TA, Goss LJ, Franceschi VR (2002). The role of druse and raphide calcium oxalate crystals in tissue calcium regulation in Pistia stratiotes leaves . Plant Biology, 4,34-45.
[19]	Wang RZ (2006). The occurrence of C₄ plants and their morphological functional types in the vegetation of Xinjiang, China . Photosynthetica, 44,293-298.
[20]	Wang XL (王勋陵), Ma J (马骥) (1999). A study on leaf structure and the diversity of xerophytes ecology adaptation. Acta Ecologica Sinica (生态学报), 19,787-792. (in Chinese with English abstract)
[21]	Wang XL (王勋陵), Wang J (王静) (1989). Plant Morphological Structure and Environment (植物形态结构与环境) 1st edn. Lanzhou University Press, Lanzhou, 57-87. (in Chinese)
[22]	Ward D, Spiegel M, Saltz S (1997). Gazelle herbivory and interpopulation differences in calcium oxalate content of leaves of a desert lily. Journal of Chemical Ecology, 23,333-347.
[23]	Wyssling AF (1981). Crystallography of the two hydrates of crystalline calcium oxalate in plants. American Journal of Botany, 68,130-141.
[24]	Xiao W (肖雯) (2002). Microstructures in the nutritional organs of five halophytes. Journal of Gansu Agricultural University (甘肃农业大学学报), 37,421-427. (in Chinese with English abstract)
[25]	Yu FG (喻富根), Li ZL (李正理) (1991). Anatomy of the lithocyst in the epidermis of leaf in Broussonetia papyrifera . Acta Botanica Sinica (植物学报), 33,249-255. (in Chinese with English abstract)
